Low Pressure 200 L Solar Water Heater

FOB Reference Price:Get Latest Price
US $99-255 / Units | 1 Unit/Units non pressure solar water heater (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Evacuated Tube
Pressure:
Unpressurized
Circulation Type:
Direct / Open Loop (Active)
Heating System:
Thermosyphon (Passive)
Connection Type:
Direct-Plug
Installation:
Freestanding
Housing Material:
Galvanized Steel
Certification:
CE, ISO9001
Capacity:
200
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
DIYI&OEM
Model Number:
DIYI-NP01
Color:
White and Grey
Inner tank::
SUS 304-2B/0.41mm
Out tank::
Galvanized steel/0.41mm
Vacuum tube::
58x1800mm SS-Cu-AIn/AlN coating
Bracket::
Galvanized steel 1.2mm 0-50degree
Insulation::
High density polyurethane foam 50mm
Tank Capacity::
150L, 180L, 200L, 250L, 300L
Assistant tank::
5 L
Certificates::
ISO/TUV/ROHS/CE
SupplyAbility
SupplyAbility:
1000 Unit/Units per Week solar water heater
Packaging & Delivery
Packaging Details
Carton Box for full container & Wooden Box for sample
Port
Shanghai
Lead Time :
Shipped in 30 days after payment

 Low Pressure 200 L Solar Water Heater

Product Description

  Product pictures of solar water heater:



Technical Parameters

 Solar Water Heater Feature:

This model solar water heater is one of the most favorite on the international market.It was scientifically and specially designed,is easy to install and operate.The important point is it can feed water automatically and ensure the outlet water as stable temperature,it will always provide you hot water.

Technical Parameters:

Inner tank: SUS 304-2B/0.41mm

Outer tank: Galvanized steel/0.31mm

Insulation: high density polyurethane foam 50mm

Vacuum tube: 58*1800mm       AL-N-AL coating

Bracket:Galvanized steel 1.2m     0-50 degree

Accessories:UV stablilized high temperature silicon

Capacity: 100L 150L 200L 250L 300L



Type

Area(M2)

Vacuum tube

Volume(L)

GrossWeight (KG)

20GP/40GP/40HQ   Loading Qty(sets)

Φ(mm)

Length(mm)

Qty(pcs)

DIYI-NP01-15

1.979

58

1800

15

150

78

53/109/130

DIYI-NP01-18

2.382

58

1800

18

180

85

48/93/112

DIYI-NP01-20

2.651

58

1800

20

200

94

40/82/98

DIYI-NP01-25

3.189

58

1800

25

250

97

30/64/75

DIYI-NP01-30

3.995

58

1800

30

300

112

25/52/62
